Article number: SCB5DL
SCB 5 DL is an illuminated mushroom pushbutton intended to operate our Man in Cold Room Alarm, SCA 1 AL. The button has a sturdy metall frame that protects the mushroom pushbutton against breakage. It is well suited for use in harsh environments. SCB 5 DL consists of a pushbutton, one normally open and one normally closed Contact, and an LED indicator mounted in a plastic enclosure.
• Mushroom push button.
• Push button locks in the depressed position.
• Resets by pulling the button.
• Size: 186 x 85 x 126
• Make contact.
• 12V LED, 24mA.
• Brightness 10-12cd.
• Yellow metal frame, red button and light, black plastic encapsulation.
• -30°C <-> +40°C.
• Ex II 2 G.
